Dolby Atmos
With Dolby Atmos, sound comes alive from all directions, including overhead, to fill the home theater with astonishing clarity, power, detail, and depth. The AVR-X4100W has the processing power to run a more enveloping, Audyssey MultEQ XT32 calibrated 7 or 9 channel Dolby Atmos layout using 5.1.2, 5.1.4* or 7.1.2* configurations utilizing ceiling mounted, or Dolby Atmos-enabled speakers. A 5.1.2 speaker configuration is based upon a traditional 5.1 speaker layout complemented by 2 overhead or Dolby Atmos-enabled speakers. A 5.1.4 configuration is based on a 5.1 speaker layout with 4 overhead, or Dolby Atmos-enabled speakers. A 7.1.2 configuration is based on a 7.1 speaker layout with 2 overhead, or Dolby Atmos-enabled speakers. (* with additional power amplifier)
Equipped with 7+1 input and 2+1 output HDMI terminals that fully support next-generation 4K displays
Eight systems are provided for the 4K video signal supporting HDMI input. One of these systems is located at the front so that you can easily enjoy video from a movie camcorder, game console, or smart phone. The HDMI output has a new terminal for zone output in addition to 2 systems capable of simultaneous output to allow the HDMI input video and audio to be output to a sub-zone
Built-in Bluetooth, Built-in Wi-Fi and AirPlay, DLNA
Many portable devices are equipped with Bluetooth wireless connectivity, and the AVR-X4100W’s built-in Bluetooth wireless technology lets you stream your favourite audio tracks from up to 8 Bluetooth enabled devices, such as smartphones, portable audio players and tablets. With the built-in Wi-Fi wireless technology, the AVR-X4100W connects to the internet through your home network, opening up a world of music from internet radio stations, as well as streaming subscription service Spotify via very latest Spotify Connect scheme. With AirPlay, you can enjoy listening to your tracks wirelessly from your portable iOS device, including iPhone, iPod touch, and iPad. DLNA 1.5 certification lets you connect to your PC or Mac via your home network wirelessly for additional streaming capabilities. Our Denon Remote App lets you easily control the AVR-X4100W with your portable device, and is available for Apple and Android devices as well as the Kindle Fire
Easy To Setup, Easy To Use
Denon’s exclusive Setup Assistant, along with our Quick Start guide, will have your system properly connected and configured quickly and easily, so you can start enjoying superb home theater surround sound with a minimum of fuss and bother. The Setup Assistant features clear on-screen graphics and text that quickly and easily guide you through the setup process, optimizing critical system settings for the best possible sound quality
Powerful 7 Channel Discrete Amplifier with Eco Mode
With each channel rated at a maximum power of 200 watts, the AVR-X4100W features a power amplifier design that incorporates multiple high current discrete output devices, with identical circuit topology on all 7 channels. Our new Eco Mode provides the ability to reduce overall power consumption and features an on-screen Eco Meter that lets you see the power consumption reduction effect. The Auto Eco mode automatically switches between normal and Eco modes, depending on the volume level chosen, and the power amplifier block is rated to drive low impedance speaker loads, down to 4 ohms, for compatibility and stability with virtually any loudspeaker model
Audyssey MultEQ-XT32 / LFC
It is the most accurate room correction solution with more than ten thousand individual control points allowing finer details of the room’s problems to be captured and corrected. The ultra high resolution filters are applied to all channels including the two independent subwoofers, with the most obvious benefit being heard in the low frequency range where correction is needed the most. Audyssey LFC uses psychoacoustic algorithms to prevent bass from passing your walls and disturbing your neighbours while maintaining the bass performance in the listening room. The AVR-X4100W is also Audyssey Pro ready for the most advanced professional room correction
Multiroom / Multisource
The AVR-X4100W lets you enjoy a program source in the Main Zone (the room where the AVR-X4100W is located) and in Zone 2 and Zone 3. The source can be the same for all zones, or you can enjoy different sources in those zones if you prefer. The sources for the zones can be either analogue or 2 channel digital PCM sources (incl. optical, coaxial, HDMI and network)
Specifications:
Multichannel Surround
DTS HD Master / DTS ES / DTS 96/24
Dolby TrueHD
Audyssey DSX
DTS-Neo:X: (9ch)
Multichannel Stereo
max. number of processing (preamp) channels: 9.2
Dolby Atmos: 5.1.2, 5.1.4*, 7.1.2* configurations; *with additional 2ch power amplifier
Sound Enhancement
Discrete Power Amplifier
D.D.S.C. HD Digital
Pure Direct
High Grade Audio Components
Clock Jitter Reducer
Allpha Processing: AL24 Processing Plus
Denon Link HD
Audyssey: MultEQ XT32 (Pro ready)
Audyssey Dynamic EQ / Dynamic Volume
Audyssey LFC
Compressed Audio Restorer
Network
DLNA Certified: (v1.5)
Lossy formats MP3 / WMA / AAC
Lossless formats FLAC / ALAC / WAV
FLAC HD 192/24
WAV 192/24
AIFF 192/24
ALAC 96/24
DSD
Gapless playback: (FLAC, WAV, AIFF, ALAC, DSD)
Photo streaming (JPEG)
AirPlay audio streaming
Windows PlayTo / Windows8 certified
Internet Radio (vTuner)
Spotify: Spotify Connect
Compatible with Remote APP for Smart Phones: Android/iOS
Ethernet
WiFi
Bluetooth
HDMI
HDMI inputs back / front: 7 / 1
HDMI outputs main / zone: 2 / 1
Video conversion Analog -> HDMI
Analogue to HDMI scaling: (up to 4k 60Hz)
HDMI to HDMI scaling: (up to 4k 60Hz)
GUI Overlay on HDMI
3D signal pass-through
4k signal pass-through / scaling / GUI overlay
4k 60Hz pass-through
HDMI pass-through in standby mode
Picture adjust / Noise reduction
CEC
DSD Audio capability: (via HDMI and Network)
Audio Return Channel
Auto LipSync
Multiroom / CI
Multiroom zones: 3
Zone audio source: HDMI / opt, koax / Network, USB / analog: o (2ch) / o (2ch) / o / o
Zone audio output: speaker / preout
IP control / RS232 control / Web control / App control
Remote In / Out
DC Trigger output: 2
Other
Auto speaker setup by microphone: Audyssey MultEQ XT32 (Pro ready)
FL Display: 2 lines
Graphic User Interface - GUI: Advanced
GUI languages: 9
Setup Assistent
Firmware Update by Network / USB
Variable cross over
Optimized Bass Redirection
Auto Power off
Eco Mode
Sleep Timer
Inputs / Outputs
Composite In / Out: 3+1 / 2
Component In / Out: 2 / 1
HDMI In / Out: 7+1 / 3
Multi-Room Video Out: Video / HDMI
Analogue In: 5+1
Phono (MM) In
Digital Optical In: 2
Digital Coaxial In: 2
Multi-Room Out analog: 2
Multichannel Pre Out / Main In: (11.2)
Subwoofer Out: 2 (independent)
Speaker Terminal: Regular screw
Number of speaker terminals: 11
Speaker A / B: assignable
Bi-amp drive: assignable
Multi-Room Speaker Terminal: assignable
Remote Control In / Out
Network: (IP-control / update)
RS232C
DC Triggers: 2
Front Inputs: Audio / Composite / HDMI / USB
USB Audio / Made for iPod / Works with iPhone
Specifications:
Number of poweramps: 7
Power Output (6 ohm, 1 kHz, 1% 1ch Drive): 200 W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive): 165 W
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive): 125 W
FM Tuner with RDS
General
Metal Front Panel
System Remote Control: RC-1193
Pre-programmed
Power Consumption in W: 670 W
Power Consumption No-Sound (Eco on / off) in W: 55 W / 85 W
Standby Consumption in W: 0.1 W
CEC Standby Consumption in W: 0.5 W
Network Standby Consumption in W: 2.7 W
Approximate Dimensions:
Height: 6.57"
Width: 17.08"
Depth: 15.31"
Approximate Weight:
Unit: 27.78 lbs
Shipping: 32 lbs
