Amplifier Section
Power Output
Front L/R 160 W/Ch (6, 1 kHz, 1%, 1 channel driven, IEC)
Center 160 W (6, 1 kHz, 1%, 1 channel driven, IEC)
Surround L/R 160 W/Ch (6, 1 kHz, 1%, 1 channel driven, IEC)
Surround Back L/R, Front High L/R, or Front Wide L/R 160 W/Ch (6, 1 kHz, 1%, 1 channel driven, IEC)
Dynamic Power 240 W (3, Front) 210 W (4, Front) 120 W (8, Front)
THD+N (Total Harmonic Distortion + Noise)0.08% (20 Hz–20 kHz, Half power)
Damping Factor 60 (Front, 1 kHz, 8)
Input Sensitivity and Impedance 200 mV/47 k (Line)
Rated RCA Output Level and Impedance 200 mV/2.2 k (Rec out)
Maximum RCA Output Level and Impedance 2.0 V/2.2 k (Rec out)
Frequency Response 5 Hz–100 kHz/+1 dB, -3 dB (DSP bypass)
Tone Control 10 dB, 50 Hz (Bass) 10 dB, 20 kHz (Treble)
Signal-to-Noise Ratio 106 dB (Line, IHF-A)
Speaker Impedance 4–16 or 6–16
Video Section
Input Sensitivity/Output Level and Impedance
Video 1.0 Vp–p/75 (Component Y) 0.7 Vp–p/75 (Component PB/CB, PR/CR) 1.0 Vp–p/75 (Composite)
Component Video Frequency Response 5 Hz–100 MHz/0 dB, -3 dB
Tuner Section
Tuning Frequency Range
FM 87.5 MHz–108 MHz
AM 522 kHz–1,611 kHz 530 kHz–1,710 kHz
FM/AM Preset Memory 40 stations
General
Power Supply AC 220–240 V, 50/60 Hz
Power Consumption 610 W
Dimensions (W x H x D) 435 x 173.5 x 328 mm
Weight 11.3 kg
CARTON
Dimensions (W x H x D) 570 x 297 x 423 mm
Weight 15.0 kg
